CANopen
6 Parameter setting
6-33
L
BA2175 EN 2.0
Subindex Rights
Explanation
Subindex Rights
Write Read
0 ro
• The following error message occurs while
writing: 0601 0002 Supported subindex = 3
1
Reading of memory functions of all
parameters The following functions are possible
(depending on the controller) and
represented by reading the values
f bit iti 0 d 1
2
rw
• This function is not
Reading of memory functions of
communication parameters (objects
of the 2175 fieldbus module)
p y g
of bit positions 0 and 1:
Value 0: No saving
Value 1: Saving on command
Value 2: Automatic saving
3
This function is not
supported yet
• The following error
message occurs while
writing:
0800 0020
Reading of memory functions only
of manufacturer-specific
parameters
(range: 6000
hex
- 9FFF
hex
)
g
Value 3: Automatic saving and
saving on command
6.4.1.11 1011
hex
: Restore default parameters
Download of default settings.
Tip!
With this function the subindex used depends on the controller type.
Index [hex] Subindex Name Data type Authorisation
1011 0 ... 3 Restore default parameters U32 rw/ro
In addition to index and subindex, telgram data must include the signature“ load “ to start the
parameter download (see table).
Signature MSB LSB
ISO 8859 (ASCII) d a o l
hex 64 61 6F 6C
Bit assignment for reading right
U32
0 1 - 31
0: Download not
possible
1: Download possible 0 0 0 .. 0 0 0
Subindex Rights Write Read
0 ro
• The following error message occurs
while writing:
0601 0002
hex
Max. available subindex depends on controller type:
• 7: 8200 vector frequency inverter
• 5: 82XX frequency inverter
• 3: 93XX servo inverter
1
All parameters can be Function not available for
1
All parameters can be
downloaded
8200 vector 82XX 93XX
2
Download of communication
parameters only (objects of the
2175 fieldbus module)
X X X
3
rw
• This function is not
supported yet
Download of
manufacturer-specific
parameters only (index 6000
hex
-
9FFF
hex
)
X X X
4
rw supported yet
• The following error
message occurs
Download of parameter set 1
possible
X X
5
message occurs
while writing:
0800 0020
hex
Download of parameter set 2
possible
X X
6
0800 0020
hex
Download of parameter set 3
possible
X
7
Download of parameter set 4
possible
X
