DeviceNet

12

Parameter setting

12-5

L

BA2175 EN 2.0

Vendor-specific class (class 101) (GET/ SET)

Instance 1

Attribute 1: Process data monitoring code (2 byte)

0: No response (default)
1: Controller inhibit
2: Quick stop
This setting is saved as non-volatile value in the EEPROM.

Vendor-specific class (class 102) (GET/ SET)

Instance 1

VSC attribute 1: Process data length (2 byte)

0: Default value according to EDS file
1: 2 byte
...
12: 24 byte
Note: When changing the process data length, the process data length in the master must be adapted under ”produced / consumed data size”.
