DeviceNet
12 Parameter setting
12-6
L
BA2175 EN 2.0
12.1 Communication-relevant Lenze codes
Tip!
If the 2175 module is plugged onto a different controller during operation, an undefined operating
status might occur.
The behaviour of servo inverters and frequency inverters is determined by their parameters. Lenze
controllers can be parameterised by codes. These (Lenze) codes are exchanged between master
and 2175 fieldbus module as part of a telegram and via a CAN bus.
Depending on the Lenze inverter, two codes are available for communication via CAN bus: L-C1810
and L-C1811.
Communication with the drive is only possible when the controller is know as system device. The
devices are detected while the modules are initialised.
Address and baud rate can only be set using the front switch:
•
Switches 1 - 9 ≠ OFF (see chapter 10)
•
Switch 10 = OFF: DeviceNet communication profile
12.1.1 Description of communication-relevant Lenze codes
How to read the table
Column Meaning
Code (Lenze) code
Subcode Subcode
Index Incidated as hexadecimal/decimal value
Lenze Code default setting
Selection Minimum value [smallest step/unit] maximum value
Data type VS: Visible string, indicated length
12.1.1.1 L-C1810: Software product code
Possible settings
Code Subcode Index Lenze Selection Data type
L-C1810 - 22765
d
= 58ED
h
- - Visible string
During module initialisation the bus devices are defined by means of the product code.
12.1.1.2 L-C1811: Software date
Possible settings
Code Subcode Index Lenze Selection Data type
L-C1811 - 22764
d
= 58EC
h
- - Visible string
This date is mainly needed for service.
