AT-S41 User’s Guide
98
1. From the VLAN Creation Menu, type Q to select Quit to Previous
Menu.
The VLAN Management Menu is displayed again.
2. Type S to select Set Port Config.
The VLAN Port Configuration Menu is displayed in Figure 26.
Figure 26 VLAN Port Configuration Menu
This menu lists the ports on the switch and each port’s current PVID
assignment. For example, in the figure above, Ports 1 to 8 on the
switch all have a PVID of 1, meaning that they are untagged members
of the Default VLAN, which has a VID of 1.
The menu, when initially displayed, lists the PVIDs for the ports on the
master switch of the stack.
3. Type I to choose Select Stack [I]D and enter the number of a switch in
the stack containing a port whose PVID you need to change if the port
is on a slave switch.
The VLAN Port Configuration Menu for the selected switch is
displayed.
4. To set a PVID, type V to select the Set Port VID option.
The following prompt is displayed:
Set PVID->Enter port number>
AT-8350GB Local Management System
VLAN Management -> VLAN Port Configuration Menu
Stack ID: 1
Port PVID
---- ----
1 1
2 1
3 1
4 1
5 1
6 1
7 1
8 1
-------------------------------- -----------------------
[N]ext page Set Port [V]ID
[P]revious Page Set Stack [I]D
[Q]uit to previous menu
Command> _
Enter the character in square brackets to select option
