AT-S41 User’s Guide
124
Activating IGMP Snooping
To enable or disable IGMP snooping on the switch and to configure
IGMP snooping parameters, perform the following procedure:
1. From the Main Menu, type A to select Advanced Switch
Configuration.
2. From the Advanced Switch Configuration Menu, type I to select the
IGMP Snooping Configuration.
The IGMP Configuration Menu is displayed in Figure 32.
Figure 32 IGMP Configuration Menu
The parameters in the IGMP Configuration Menu are defined
below:
[E]nable/Disable IGMP Snooping
Enables and disables IGMP snooping on the switch. After
selecting this option, type E to enable or D to disable this feature.
[S]et Age Out Timer
Specifies the time period in seconds after which the switch stops
sending out multicast packets out of a port with an inactive host
node. An inactive host node is a node that has not sent an IGMP
report during the specified time interval. The range is from 280 to
420 seconds. The default is 280 seconds.
AT-8350GB Local Management System
Enter the character in square brackets to select option
Advanced Switch Configuration -> IGMP Configuration Menu
IGMP Snooping Status: Disabled
IGMP Snooping Age-Out Timer : 280 seconds.
VLAN ID Multicast group address
------- -----------------------
2 224.0.1.22
7 224.0.1.25
--------------------------- ------------------------------
[N]ext Page [E]nable/Disable IGMP Snooping
[P]revious Page [S]et Age Out Timer
[V]iew group members [Q]uit to previous menu
Command>
Enter the character in square brackets to select option
