AT-S41 User’s Guide
203
Viewing or Modifying a VLAN
There are two phases to modifying a VLAN. You might need to perform
both phases or just one, depending on what it is you want to change in
the VLAN. The phases are:
❑ Phase 1: In this phase, you can view a VLAN’s configuration, as well
as change a VLAN’s name and add or remove tagged ports.
❑ Phase 2: In this phase, you can add or remove untagged ports.
Phase 1 This phase explains how to change a VLAN’s name and add or remove
tagged ports.
Note
If you do not want to change a VLAN’s name or add or remove
tagged ports, then continue to Phase 2 to add or remove untagged
ports.
1. Click on the Advanced Config menu tab and select VLAN Config from
the sub-menu. Select VLAN Info from the next sub-menu.
The VLAN Information will appear, as displayed in Figure 79
Figure 79 VLAN Information
This page lists all of the VLANs that currently exist in the stack.
2. To view a VLAN’s configuration or to make changes to a VLAN, click
the Modify link in the column for the VLAN you want to view or
modify.
