AT-S41 User’s Guide
157
Configuring an IP Address
Note
For guidelines on when to assign an IP address, subnet address, and
gateway address to an AT-8350GB switch, refer to When Does an
AT-8350GB Switch Need an IP Address? on page 34.
The procedure in this section explains how to manually assign an IP
address, subnet mask, and gateway address to the switch, as well as how
to enable DHCP. If you want the switch to obtain its IP configuration
from a DHCP server on your network, go to the procedure Activating
DHCP on page 163.
To manually change a switch’s IP configuration, perform the following
procedure:
1. Click on the Basic Config menu tab and select IP Config from the sub-
menu.
The IP Configuration page is displayed, as shown in Figure 56.
Figure 56 IP Configuration Page
2. Change the IP configuration parameters by entering the new
information in the data entry fields and clicking the Apply button.
The parameters on the IP Configuration page are described
below:
