AT-S41 User’s Guide
137
The Receive File pop-up window is displayed in Figure 39.
Figure 39 Receive File Pop-up Window
8. Click the Browse button on the Receive File window to specify the
target location of the configuration file.
9. Click on the Protocol field and set to 1K Xmodem transfer protocol.
10. Click Receive.
The Receive Filename pop-up window will appear as displayed in
Figure 40.
Figure 40 Receive Filename Pop-up Window
11. Type in the filename and click OK.
The switch immediately begins to upload the configuration file
onto the workstation or server. As this process begins, the
XModem File Receive window displays current status of the
configuration file upload.
