AT-S41 User’s Guide
54
Configuring Port Parameters
To configure the parameter settings for a port on the stack, perform the
following procedure:
1. From the Main Menu, type B to select Basic Switch Configuration.
2. From the Basic Switch Configuration Menu, type P to select Port
Configuration.
The Port Configuration Menu is displayed in Figure 14.
Figure 14 Port Configuration Menu
Note
By default, the management software initially displays the ports on
the master switch. To view the ports on another switch in a stack,
use the Select Stack ID command.
The columns on the Port Configuration Menu are described
below.
Port
The port number.
Trunk
The trunk group number. A number in this column indicates that
the port is a member of a trunk.
AT-8350GB Local Management System
Basic Switch Configuration -> Port Configuration Menu
Stack ID: 1
Port Trunk Type Link Status Mode Flow Ctrl
---- ----- -------- ---- ---------- --------------- ---------
1 --- 10/100TX Down Enabled Auto Enabled
2 --- 10/100TX Down Enabled Auto Enabled
3 --- 10/100TX Down Enabled Auto Enabled
4 --- 10/100TX Down Enabled Auto Enabled
5 --- 10/100TX Down Enabled Auto Enabled
6 --- 10/100TX Down Enabled Auto Enabled
7 --- 10/100TX Down Enabled Auto Enabled
8 --- 10/100TX Down Enabled Auto Enabled
9 --- 10/100TX Down Enabled Auto Enabled
10 --- 10/100TX Down Enabled Auto Enabled
11 --- 10/100TX Down Enabled Auto Enabled
12 --- 10/100TX Down Enabled Auto Enabled
-------------------------------- --------------------------
[N]ext Page Set [S]tatus Set [F]low control
[P]revious Page Set [M]ode Select Stack [I]D
[Q]uit to previous menu
Command> _
Enter the character in square brackets to select option
