Creating a VLAN
The procedure for creating a new VLAN is divided into the following
phases:
❑ Phase 1: Assigning a VID and name and specifying the port
members
❑ Phase 2: Converting tagged ports into untagged ports
Performing Phase 1 is required whenever you create a new VLAN. Every
VLAN should have a name, VID, and ports. You will need to perform
Phase 2 if some or all of the ports of a VLAN will be untagged ports or if
you want to creat a port-based VLAN. Ports that you want to function as
untagged ports must be converted by changing their PVIDs, as
explained in Phase 2.
To create a new VLAN, start by performing the procedure in Phase 1.
Phase 1 This phase assigns a VID and a name to your VLAN and also designates
the VLAN port members.
1. From the Main Menu, type A to select the Advanced Switch
Configuration Menu.
2. From the Advanced Switch Configuration Menu, type V to select
VLAN Management.
The VLAN Management Menu is displayed in Figure 24.
Figure 24 VLAN Management Menu
AT-8350GB Local Management System
Advanced Switch Configuration -> VLAN Management Menu
GVRP Status :Disabled
VLAN ID
VLAN Name VLAN Type
------- -------------------------------- ----------
1
Default VLAN Permanent
--------------------------- ------------------------------
[N]ext Page [C]reate VLAN
C[o]nfig VLAN Member
[P]revious Page [D]elete VLAN [S]et Port Config
[R]eset VLAN to Default Set [G]VRP Status [Q]uit to previous menu
Command> _
Enter the character in square brackets to select option
