AT-S41 User’s Guide
70
Creating a Port Trunk
This section contains the procedure for creating a port trunk on a stack.
Be sure to review the guidelines in the Port Trunking Overview on
page 67 before performing this procedure.
Caution
Do not connect the cables to the trunk ports on the stack until after
you have configured the trunk with the management software.
Connecting the cables before configuring the software will create a
loop in your network topology. Data loops can result in broadcast
storms and poor network performance.
To create a port trunk, perform the following procedure:
1. From the Main Menu, type A to select Advanced Switch
Configuration.
2. From the Advanced Switch Configuration Menu, type T to select
Trunk Configuration.
The Trunk Configuration Menu is displayed in Figure 20.
Figure 20 Trunk Configuration Menu
3. Type I to select the Select Stack ID command and specify the switch
in the stack on which you want to create the port trunk.
AT-8350GB Local Management System
Advanced Switch Configuration -> Trunk Configuration Menu
Stack ID: 1
Group Status Port Members Trunk ID
----- -------- ------------------------------- --------
1 Disabled 1
2 Disabled 2
3 Disabled 3
4 Disabled 4
5 Disabled 5
6 Disabled 6
7 Disabled 7
Note: The trunk port members must be within the same port group.
The port members of each port group are shown below.
Port group 1: port 1-8 , group 3: port 17-24 , group 5: port 33-40
Port group 2: port 9-16 , group 4: port 25-32 , group 6: port 41-48
Port group 7: port 49-50
-------------------------------- ---------------------
[A]dd Trunk Member [S]et Trunk status
[R]emove Trunk Member Select Stack [I]D
[Q]uit to previous menu
Command>_
Enter the character in square brackets to select option
