AT-S41 User’s Guide
143
The TFTP Configuration File Upload/Download Menu is displayed
in Figure 48.
Figure 48 TFTP Configuration File Upload/Download Menu
The options on the menu are defined below. To select an option, type
its corresponding bracketed letter and follow the menu prompts.
Set TFTP [S]erver IP Address
This is the IP address of the server from which you are downloading
the configuration file or to which you are uploading the
configuration file.
Set Configuration [F]ile Name
The path and filename of the configuration file that is to be
downloaded onto the switch or uploaded to the server.
[U]pload Configuration File
Uploads the configuration file from your switch onto the server.
[D]ownload Configuration File
Downloads the configuration file from the server to your switch.
Set [R]etry Count
The amount of times your system will try to upload/download the
configuration file using TFTP. The Set Retry Count range is 1 - 20. The
default setting is 5.
4. Type S and enter the IP address of the TFTP server when prompted.
5. Type F and enter the configuration file name when prompted.
AT-8350GB Local Management System
Configuration File Upload/Download -> TFTP Configuration
File Upload/Download
TFTP Server IP: 0.0.0.0
Config File Name:
Retry Count: 5
------------------------- ---------------------
Set TFTP [S]erver IP Address
Set Configuration [F]ile Name
[U]pload Configuration File
[D]ownload Configuration File
Set [R]etry Count
[Q]uit to previous menu
Command>
Enter the character in square brackets to select option
