DeviceNet Modules
HE800DNM650 & HE800DNS600
B.4. DNS_TASK Transmit Queue (Device)
Figure 59: DNS_TASK Transmit Queue
Variable Meaning
BaseLow undocumented
BaseHigh undocumented
BNel undocumented
bWidth undocumented
bRear
A pointer to where the next message will be dequeue from the
queue body
bFront
A pointer to where the next message will be stored
bInner
The actual number of stored messages
bfnUser undocumented
Table 50: Transmit Queue (Device)
