MAN0577-03-en

Page 20 of 98

EO 09-0009

DeviceNet Modules

HE800DNM650 & HE800DNS600

• Create a new project

File > New > DeviceNet

• Choose DeviceNet Master (*1) and provide MAC ID

address

Insert > Master

• Choose Horner DeviceNet device (Slave) and

provide Mac address

Insert > Device

• Assign the input and output modules (*2)

Mark the Device (left Mouse click), then
Settings > Device Configuration

• Set device assignment if no automatic assignment

has occurred

Mark the Device (left Mouse click), then
Settings > Device Assignment

• Save project

File > Save

• Download

Mark the Slave (left Mouse click), then
Online > Download

• Device diagnostic

Mark the Slave (left Mouse click), then
Online > Device Diagnostic

• Transfer user data:

Write output, read input

Mark the Device (left Mouse click), then
Online > I/O Monitor

Table 5: Steps to configure a DNS600 with any DeviceNet Master.


Note (*1): Insert a Horner SmartStack DeviceNet Master (HE800DNM650). This Master is a place holder
and it is not necessary to match the connected Master.

Note (*2): The Offset addresses assigned in the Slave configuration are always related to the DeviceNet
Master.
