MAN0577-03-en
Page 7 of 98 EO 09-0009
DeviceNet Modules
HE800DNM650 & HE800DNS600
CHAPTER 1: INTRODUCTION
1.1 Scope
This manual shows how to connect and configure the DeviceNet Master or Slave Smartstack Modules.
HSyCon, a Windows
-based software package, is an easy-to-use configuration package for use with the
SmartStack COM range of fieldbus modules and Cscape or Cbreeze, a Windows™ based package for
use with the OCS/ TIU ranges. The software user’s guide is contained in this manual.
A basic level of understanding of Microsoft Windows™ technology and operation is assumed. The
manual assumes that the user is familiar with Windows 95, Windows 98, Windows NT, Win 2000 or XP.
1.2 Introduction
The Fieldbus Smartstack module range require only three stages to get them operational, these are:
1. Physical installation and connection.
2. Configuration of the fieldbus interface.
3. Configuration of Cscape / Cbreeze to map the fieldbus data.
The system is comprised of two separate software software functions, the fieldbus interface software
running independently in the COM module and the OCS/TIU firmware running in the main module. Data
and commands are exchanged via a dual port ram interface. The configuration of the COM module is via
the RS232 serial port on the module. For correct operation the number of registers assigned in the OCS
must match the number required by the Master or Slave module configuration.
The Smartstack module should be configured with the OCS/TIU software first as otherwise it will be held
in reset and cannot be configured.
