DeviceNet Modules

HE800DNM650 & HE800DNS600

6.10. Live

List


Select the menu Online > Live List for an overview of all devices physically present in the actual network
constellation. Present devices are drawn in black, all other non present devices are drawn in grey. The
live list works online. If a station is connected or disconnected, the result can be seen as soon as HSyCon
collects the latest live list from the Master board. Remember that all devices on DeviceNet have to
proceed the autobaud detection phase first to get wholly run. This can take several milliseconds.

Figure 27: Online > Live List



6.11. Change

MAC-ID


The window to change a MAC-ID opens with a double click on the address (MAC-ID) of a DeviceNet
device (slave).

Figure 28: Online > Live List > Change MAC-ID

Select the new MAC-ID in the New MAC-ID field and click on the Send button to send it to the DeviceNet
device (slave).
Note: The DeviceNet device (slave) has to support this function if this function is required.


6.12. Debug

Mode


Select the Master device by clicking on it. Then select the menu item Online > Start Debug Mode. The
System Configurator cyclically interrogates the status of the network communication on the CIF, COM or
PKV and the individual condition of the devices.
To end the Debug Mode select the menu Online > Stop Debug Mode.
