MAN0577-03-en

Page 19 of 98

EO 09-0009

DeviceNet Modules

HE800DNM650 & HE800DNS600



3.3

Configuring a SmartStack DeviceNet Master with any DeviceNet Slave


Table 4 below describes the steps to configure a Horner Smartstack DeviceNet Master to any DeviceNet
Device (Slave).

Action

Menu in the System Configurator

Create a new project

File > New > DeviceNet

Copy EDS file of the DeviceNet device (Slave), if the
device is not in the selection list.

File > Copy EDS

Choose Horner DeviceNet Master and provide MAC ID.

Insert > Master

Choose DeviceNet device and provide MAC ID address

Insert > Device

Assign the input and output modules (*1)

Mark the Device (left Mouse click), then
Settings > Device Configuration

Assign the offset addresses

Assign the Device Parameter data, if the Device needs
Parameter data

Mark the Device (left Mouse click), then
Settings > Device Configuration >
Parameter Data

Set the Bus parameter

Mark the Master (left Mouse click), then
Settings > Bus Parameters

Set device assignment if no automatic assignment has
occurred

Mark the Master (left Mouse click), then
Settings > Device Assignment

Save project

File > Save

Download

Mark the Master (left Mouse click), then
Online > Download

Live list

Mark the Master (left Mouse click), then
Online > Live List

Start Debugger

Mark the Master (left Mouse click), then
Online > Start Debug Mode

Device diagnostic

Mark the Slave (left Mouse click), then
Online > Device Diagnostic

Stop Debugger

Online > Stop Debug Mode

Global Diagnostic

Mark the Master (left Mouse click), then
Online > Global State Field

Transfer user data:
Write output, read input

Mark the Master (left Mouse click), then
Online > I/O Monitor

Table 4: Steps to Configure DNM650 with any DeviceNet Slave.


Note (*1)
: The Offset addresses assigned in the Slave configuration are always related to the Master.


3.4

Configuring a SmartStack DeviceNet Slave with any DeviceNet Master


Table 5 below describes the steps to configure a Horner DeviceNet Slave to any DeviceNet Master as it is
typical for many cases.

Action

Menu in the System Configurator
