DeviceNet Modules
HE800DNM650 & HE800DNS600
1.6 Status
LED
definitions
Signal LED
Colour State
Definition
NET
RED
ON
Critical Link Failure
Flashing
Connection Time out
OFF
Device Not Powered
GREEN
ON
ON-LINE Link OK
Flashing
ON-LINE, Not connected
OFF
Device Not Powered
MOD
RED
ON
Unrecoverable Fault
FLASHING Minor
Fault
OFF No
Power
GREEN
ON Normal
Operation
FLASHING Configuration
Failure
OFF No
Power
RDY
YELLOW
ON COM
ready
FLASHING CYCLIC
Bootstrap Loader Active
FLASHING NON CYCLIC Hardware or System Error
OFF Hardware
Error
RUN
GREEN
ON Communication
Running
FLASHING NON CYCLIC Parameter Error
OFF Communication
Stopped
Status Signals of the DNM650 and DNS600
1.7
Main Functions
The main functions of the DEVICENET System Configurator are:
• Universal Fieldbus Configurator - Configuration of the complete Fieldbus range with one package.
•
Documents Fieldbus system - detailed documentation of the Fieldbus network may be printed.
• Standardised configuration files – allows use of protocol specific standardised configuration files.
• Diagnostic tool – upon configuration download the software may be switched into diagnostic mode.
