MAN0577-03-en
Page 56 of 98 EO 09-0009
DeviceNet Modules
HE800DNM650 & HE800DNS600
6.19. Extended Device Diagnostic Device (Slave)
PLC_TASK
DNS_TASK
Task / Task State Page
PLC_Task Common Variables (Device) 94
DNS_Task Common Variables 95
DNS_TASK Receive Queue (Device) 96
DNS_TASK Transmit Queue (Device) 97
Table 16: Extended Device Diagnostic Device (Slave)
6.20. User
Data Transfer
The following table shows test functions with user data transfer and the usability for
• Horner DeviceNet Master devices
• Horner DeviceNet Slaves
User data transfer
function Usage Usable with
Horner
DeviceNet
Master devices Usable with
Horner
DeviceNet
Master devices
I/O Monitor Read input data and set output data.
(cyclic I/O data exchange) Yes Yes
I/O Watch Read input data and set output data.
(cyclic I/O data exchange) Yes Yes
Get Device Attribute
and
6.25Set Device
Attribute Get and Set attribute Yes No, only for
Horner Master
devices
Table 17: Overview User Data Transfer
Further test functions with user data transfer are available for
• Explicit Messaging for DeviceNet Master in section Message Monitor for testing explicit messaging
of DeviceNet
• on page 62.
