DeviceNet Modules

HE800DNM650 & HE800DNS600

B.3. DNS_TASK Receive Queue (Device)

Figure 58: DNS_TASK Receive Queue (Device)

The Receive Queue is used to monitor the receive transmission queue of the internal CAN controller.

Variable Meaning

BaseLow undocumented

BaseHigh undocumented

BNel undocumented
bWidth undocumented

bRear

A pointer to where the next message will be dequeue from the
queue body

bFront

A pointer to where the next message will be stored

bInner

The actual number of stored messages

bfnUser undocumented

Table 49: DNS_TASK Receive Queue (Device)
