Software User Guide
186
hdrType
STRING
Unknown, None, Rev0, RevA ‐ The CDMA/EV‐DO sub type
cdmaRoaming
STRING
Home, Roaming, Roaming ‐ unknown. Roaming type indicator inside or
outside the providers home network.
hdrRoaming
STRING
None, Roaming ‐ SIDS Guaranteed, Roaming ‐ SIDS Not Guaranteed. EV‐
DO Roaming state.
roaming
INTEGER
0, 1. 0 currently not roaming, 1 currently roaming.
currentState
INTEGER
Connecting, Dormant, Connected, Disconnected, Error, CallIncoming.
Current Modem State.
speedPref
STRING
Automatic, CDMAonly, EVDOonly. What speed preference the modem is
currently set to lock to.
roamPref
STRING
HomeOnly, HomePreferred ‐ AUTO, RoamOnly, Aonly, Bonly, AutoA,
AutoB, unknown. The current setting for the modem's network roaming
preference.
devName
STRING
The device name as presented by the operating system.
ifName
STRING
The cellular interface name, if known, as presented by the operating sys‐
tem (e.g. ppp0).
txCount
INTEGER
Current Wireless PPP TX byte count since connection has been up,
updated every 30 mins
rxCount
INTEGER
Current Wireless PPP RX byte count since connection has been up,
updated every 30 mins
gprsState
STRING
The “state” of the GSM connection: idle, ready, standby
rxLevel
STRING
The signal level seen at the receiver measured in ‐dBm
servingCell
STRING
The Current Cell on which the device is camped.
rrcState
STRING
Radio Resources Control State (also called Packet Data Transfer state):
idle, CELL_DCH, CELL_FACH, CELL_PCH, and URA_PCH
gsmChannel
STRING
Indicates which GSM channel or band of frequencies the device is cur‐
rently connected to.
psState
STRING
Pulls CELLMODEM_PS_STATE from /var/log/wireless.cardstats
mode
STRING
Pulls CELLMODEM_MODE from /var/log/wireless.cardstats
temperature
STRING
Pulls CELLMODEM_TEMPERATURE from /var/log/wireless.cardstats
simContextApn0
STRING
Pulls CELLMODEM_SIM_CONT_APN0 from /var/log/wireless.cardstats
simContextApn1
STRING
Pulls CELLMODEM_SIM_CONT_APN1 from /var/log/wireless.cardstats
simStatus
STRING
Pulls CELLMODEM_SIM_STATUS from /var/log/wireless.cardstats
serviceDomain
STRING
Pulls CELLMODEM_SERVICE_DOMAIN from /var/log/wireless.cardstats
availServiceType
STRING
Pulls CELLMODEM_AVAIL_SERVICE_TYPE from /var/log/wireless.card‐
stats
wCdmaL1State
STRING
Pulls CELLMODEM_WCDMA_L1_STATE from /var/log/wireless.cardstats
mmccState
STRING
Pulls CELLMODEM_MM_CS_STATE from /var/log/wireless.cardstats
gmmPsState
STRING
Pulls CELLMODEM_GMM_PS_STATE from /var/log/wireless.cardstats
wCdmaChannel
STRING
Pulls CELLMODEM_WCDMA_CHANNEL from /var/log/wireless.cardstats
wCdmaBand
STRING
Pulls CELLMODEM_WCDMA_BAND from /var/log/wireless.cardstats
systemMode
STRING
Pulls CELLMODEM_SYSTEM_MODE from /var/log/wireless.cardstats
powerOnTime
STRING
Pulls CELLMODEM_POWERON_TIME from /var/log/wireless.cardstats
lowSpeedCsq
STRING
Pulls CELLMODEM_LOWSPEED_CSQ from /var/log/wireless.cardstats
highSpeedCsq
STRING
Pulls CELLMODEM_HIGHSPEED_CSQ from /var/log/wireless.cardstats
band
STRING
Pulls CELLMODEM_BAND from /var/log/wireless.cardstats
imei
STRING
Pulls CELLMODEM_IMEI from /var/log/wireless.cardstats
simId
STRING
Pulls CELLMODEM_SIM_ID from /var/log/wireless.cardstats
