Page 14: Interface configuration

Software User Guide
14
Cellular Configuration
Address and Signal Strength. If you do not see an IP Address get populated for the PPP interface you may have an issue
with your settings or your account has not been correctly activated.
Activation Status column: See table below for a description of the different statuses found in the “Activation Status” col‐
umn.
2.1.1
Cellular Interface Configuration
•
Select Yes to enable the interface so it becomes active after the new settings are applied and upon subsequent
system start‐up. Select No to disable the cellular connection feature. More information on setting up the unit’s
cellular connection can be found in
2.1.2
Set the User Name, Password and APN
If you are using a GPRS, Edge or HSDPA based card, enter the User Name, Password and APN that was provided by your
cellular carrier. This information should have been packaged with your SIM chip. If you do not have this information,
please contact your carrier’s account representative or the carrier’s support department before proceeding.
Click the “Apply” button to save and activate the configuration.
CDMA
HSPA/LTE
Running - Connection/Activation is running
Not Reg - Modem not registered
Waiting - Connection/Activation tried and failed. Will
retry in 20 mins.
Reg Home - Registered on Home Network
Succeeded - Connection/Activation successful
Searching - Searching for connection
Unavailable - connection/Activation not supported
Reg Denied - No SIM or SIM no longer activated
Failed - Connection/Activation Failed
Unkn Stat - Unknown status
Available - Activation not running/Module has not tried
to connect/Module already activated
Reg Roam - Registered on roaming network
