Apple iMac G5, 20-inch User Manual
Page 71
iMac G5 (20-inch) Take Apart -
Logic Board
15. Connect the modem to the logic board and replace the two modem screws.
16. Place the AirPort card guide on the logic board and:
• replace the two screws on the Airport Extreme card guide
• connect the AirPort antenna cable (to the AirPort Extreme card or to the card
guide) and slide the AirPort antenna into of the slot on the card guide
• connect/replace the power supply
