Apple iMac G5, 20-inch User Manual
Page 46
44 - iMac G5 (20-inch) Take Apart
Fans, Upper
3.
Depending on the type of screws present (Torx 8 or Phillips #2), loosen the two fan
screws. Note: You don’t have to remove the screws from the rubber grommets to
remove the fan, just loosen the screws.
4.
Disconnect the fan cable from the connector on the logic board. Pull on the black
connector, not on the wires.
