iMac G5 (20-inch) Take Apart -

Midplane Assembly-Short Cut

8.

Connect the two hard drive cables and lower the hard drive into the midplane.

9.

Reconnect the black cable to the white connector on the side of the hard drive. If

required, use a needlenose pliers to push the cable into the white connector.
