114 - iMac G5 (20-inch) Take Apart

Midplane Assembly

3.

Locate the optical drive in the top left corner.

4.

Using the tool provided, or a Phillips #1 screwdriver, remove the four optical drive

screws circled below. Set the screws aside.
