Midplane assembly, Tools required, Preliminary steps – Apple iMac G5, 20-inch User Manual
Page 114: Part location
112 - iMac G5 (20-inch) Take Apart
Midplane Assembly
Midplane Assembly
Tools Required
• Use the screwdriver provided, or a Phillips #1 screwdriver, preferably with a
magnetized tip
• Needlenose pliers
• Screw tray or equivalent to hold the screws
Preliminary Steps
Before you begin, remove the back cover.
Part Location
