Microphone cable, Tools required, Preliminary steps – Apple iMac G5, 20-inch User Manual
Page 194: Part location
192 - iMac G5 (20-inch) Take Apart
Microphone Cable
Microphone Cable
Tools Required
• Needlenose pliers
Preliminary Steps
Before you begin, remove the following:
• Back cover
• Midplane
• Light pipe
• Power supply
Note: Although the power supply may remain in place, the procedure is easier if it is
removed.
Part Location
