54 - iMac G5 (20-inch) Take Apart

Logic Board

Tools

• Phillips #2 screwdriver

• Torx-10

• Torx-6

• Flat blade screwdriver

• Screw tray or equivalent to hold the screws

Preliminary Steps

Before you begin, do the following:

• Remove the back cover

• Remove the optical drive

• Remove the memory

• Disconnect the power supply cable (black connector)

•

Important: Position the DIMM latches into the locked position (closed) during

installation; the DIMM latches are very fragile and must be protected.
