Replacing the lcd panel – Apple iMac G5, 20-inch User Manual
Page 182
180 - iMac G5 (20-inch) Take Apart
LCD Panel
Replacing the LCD Panel
1.
Check the routing of the LCD panel cables.
Note: The replacement LCD panel includes the brackets, cables, tape, and gaskets,
as shown.
2.
To avoid leaving fingerprints on the display screen, make sure your fingertips touch
only the metal frame of the display.
3.
Make sure the cables cannot be pinched when setting the LCD panel in the bezel.
