Page 110: Part location
108 - iMac G5 (20-inch) Take Apart
Modem Board
Modem Board
Tools Required
• Torx T6 screwdriver, preferably with a magnetized tip
• Screw tray or something equivalent to hold the screws
Preliminary Steps
Before you begin, remove the following:
• Back cover
• AirPort Extreme Card
• AirPort Extreme Card holder
Part Location
