32 - iMac G5 (20-inch) Take Apart Inverter
10. Rotate the computer clockwise so you see the inverter cables as shown below. Tilt the
inverter to access the two white cable connectors with the pink and blue cables.
11. Disconnect the cables by pulling on the connector, not on the cables. Disconnect the
smaller connector first.
12. Important: When removing the inverter, be careful of the memory DIMM connector
latches. Carefully slide out the inverter without making contact with the DIMM
connector latches. Disconnect the black connector (circled below) located under the
gray fan duct. Gently pull the black cable to disconnect the connector.
