Speaker set, Tools required, Preliminary steps – Apple iMac G5, 20-inch User Manual
Page 200: Part location
198 - iMac G5 (20-inch) Take Apart
Speaker Set
Speaker Set
Tools Required
• Needlenose pliers
• Torx T10 screwdriver, preferably with a magnetized tip
• Flat-blade screwdriver
• Screw tray or something equivalent to hold the screws
Preliminary Steps
Before you begin, remove the following:
• Back cover
• Midplane
• Light pipe
Part Location
