Configuring SCSI Routing

126

IP Storage Router SR2122-2 User Guide

With VLAN

To assign a server interface and VLAN to a SCSI routing instance:

1. enable — Enter Administration mode.

2. SCSIRouter zeus serverif ge2 VLAN 100 10.1.0.45/24

Assign a VLAN, identified by its VID

100, to the desired SCSI routing

instance

zeus. Specify the server interface ge2 and the IP address and subnet

mask

10.1.0.45/24 that the VLAN will use to access the SCSI routing

instance. In this example, the subnet mask of

255.255.255.0 was set using

CIDR style

/24.

Note:

To look up the VID, use the show vlan command. VIDs are listed in the VLAN

column.

Configuring iSCSI Targets

Configuring iSCSI targets consists of specifying the SCSI routing instance to
which an iSCSI target is to be assigned, specifying the iSCSI target, and mapping
the iSCSI target to a physical storage device. When assigning an iSCSI target, you
can specify the physical storage device either by physical storage address, serial
number, or by an index number assigned to the device.

Note:

When a new iSCSI target is configured, IP hosts do not have access to it. You

need to configure access to newly created iSCSI targets according to the “Configuring

Access” section later in this chapter.

Use the procedures that follow according to mapping type and storage addressing
type:

Target-and-LUN mapping using WWPN addressing

Target-and-LUN mapping using LUNWWN addressing

Target-and-LUN mapping using Serial Number addressing

Target-only mapping using WWPN addressing
