GRAPH

MODE

95

1.5kH

Enter

H

k

Backspace

All clear

Clear

If a wrong unit is entered, the value is cancelled.

Unit Mismatched

If a value outside of the range is entered, the
closest available value is automatically selected.

Nearest Available

If the entered Lo level is higher than the Hi
level, the two values are swapped.

Hi and Lo Swapped

Set Lo level

6. Press the Up/Down key to move the

cursor to Lo level and repeat the
same step.

Cs Lo:

3.5626mF
