LCR-8000G Series User Manual

30

Pass/Fail test (Multiple step)

Step Description

Details

1. Connect fixture

Connect the fixture to the DUT.

Page24

2. Set buzzer
sound

Press the Menu key, then F5 (System).
Press the Up/Down arrow key to move
the cursor to Beep, then use the
Left/Right key to select setting (Off
recommended).

Page72

3. Set Average

Press the Menu key, then F5 (System).
Press the Up/Down arrow key to move
the cursor to Average, then use the
numerical keys to enter an average
number (1-256). Press enter to confirm the
number.

Page73

4. Enter multiple
step mode

Press the Menu key, then F3 (Multi step). Page74

5. Select
measurement
item

Press the arrow keys to move the cursor
to Step 01 Func. Press F1 (Prog)
repeatedly to select the item.

Page76

6a. Set
parameters

Press the arrow keys to move the cursor
to the parameters below. Use the
numerical and unit keys for editing values
or F1 (Prog) for selecting options.

Page76

6b. Add steps

Move the cursor to the first empty step
and press F1 (Prog).

Page76

6c. Copy to the
next step

Press F2 (Copy). The selected step
contents are copied and inserted to the
next step.

Page79

6d. Delete step

Press F3 (Delete). The selected step is
deleted.

Page79

7. Save program

Press F4 (Save). The edited program is
saved.

Page83
