background image

GETTING

STARTED

23

Select AC mains frequency (50/60Hz)

Background

Although the LCR-8000G works under both 50 and
60Hz power frequencies, we recommend selecting
the frequency that matches the local setting to get
the best measurement precision, especially at
lower frequencies (< 100Hz).

Panel operation

1. Press the Menu key, then F5

(System). The system menu appears.

Menu

F 5

Precision LCR Meter LCR-8101

5

:

Frequency

Software version 2.03 Oct 25 2008

RS-232

GPIB

Graph mode

Line frequency

Beep

GPIB address

:

:

OFF

50Hz

1MHz

Average

: 10

2. Press the Up/Down key and move

the cursor to Line frequency.

:

Line frequency

50Hz

3. If necessary, press the Left/Right

key to select the frequency, from 50
to 60Hz or from 60Hz to 50Hz.

:

Line frequency

60Hz
