background image

BASIC

MEASUREMENT

51

Set measurement range to Auto

Background

The measurement range is an internal parameter
defining the search range for each measurement
item. Make sure the Auto setting is always
selected, to obtain the best measurement accuracy.
The active range appears at the top left corner of
the display.

MEASUREMENT MODE

0.01234

0.2179

nS

D

*7

Panel operation

1. Press the Left/Right key

repeatedly to move the cursor to
Range position.

Speed Slow

Range Auto

2. If the range is NOT set to Auto,

press the Up/Down key
repeatedly to set it back to Auto.

Speed Slow

Range 5

Speed Slow

Range Auto
