REMOTE

CONTROL

119

:graph:freq?

Returns the frequency if the sweep mode is drive
level

:graph:lev

Set the drive level if the sweep mode is frequency.
Parameter: (.1 volts) .1v, 100m, 1e-1, 1.000000e-1
Example: :graph:lev 100m

 NOTE: e1 or e+1 is invalid for the lev

command. 2 volts maximum.

:graph:lev?

Returns the drive level if the sweep mode is
frequency.

:graph:speed

Set measurement speed for the sweep.
Parameter: fast, med, slow
Example: :graph:speed med

:graph:speed?

Returns the measurement speed of the sweep.
Return Parameter: 1(fast), 2 (med), 3(slow)

:graph:step

Select the number of pixels between each
measured point.
Parameter: 1(step size 1),2(step size 2 ),3(step size
4),4(step size 8)
Example: (step size 8) :graph:step 4

:graph:step?

Query the current step size for the plot.

:graph:hi-lim

Set the maximum value for Y-axis in the graph
mode.
Parameter: real number up to 1^12 (1e+12)
Example: graph:hi-lim 8.5e9
Note: Set the low limit before setting the high limit.
The graph limits will only work whilst the
“autofit” function is set to “off”

:graph:hi-lim?

Returns the maximum value of Y-axis in the graph
mode.
