GRAPH MODE
87
G
RAPH MODE
The graph function shows the component
characteristics in visual manner. Voltage and
Frequency sweep are selectable for the horizontal
scale. When the graph gets out of the vertical
range, the LCR-8000G can automatically adjust
the scale. Marker operation is available for
detailed observation.
Item selection Enter graph mode ........................................... 88
Select measurement item ................................ 89
Horizontal scale
setting Set horizontal axis (Voltage) ........................... 90
Set horizontal axis (Frequency) ....................... 92
Vertical scale
setting Set vertical axis (Manual + Absolute) .............. 94
Set vertical axis (Manual + Percentage) ........... 96
Set vertical axis (Auto + Absolute) .................. 98
Set vertical axis (Auto + Percentage) ............... 99
Speed/Step
Setting Select measurement speed (capture timing) . 101
Select step size ............................................. 101
Running Graph
Measurement Run measurement ......................................... 103
Adjust vertical scale ...................................... 105
Observe Graph Data...................................... 106
