BASIC

MEASUREMENT

57

DC

AC≤
100Hz

AC≤
2kHz

AC>
2kHz

AC≥
1MHz

Slow

900ms 1.3s 600ms 600ms 620ms

Med

120ms 1.2s 470ms 450ms 470ms

Fast

60ms 650ms 180ms 150ms 150ms

Max

30ms 600ms 120ms 75ms 120ms

Beep setting

If the beep setting (page61) is active and
the display is in Pass/Fail test mode, it
might sound continuously depending
on the measurement result. If this
happens, press the Sing/Rep key and
set the mode to Single. Then turn Off
the buzzer.

Sing/Rep

Hide drive Voltage/Current

Background

The drive voltage and current shows
the actual voltage/current level
applied to the device under test.

Vm:549.8mV
Im:724.9pA

Panel operation

1. Press the Code key.

Code

2. Enter the system code using the numerical

keys, then press the Enter key.

Hide drive V/I: 80

Enter

Vm:549.8mV
Im:724.9pA

Show drive V/I: 81

Enter

Vm:549.8mV
Im:724.9pA
