LCR-8000G Series User Manual

56

Select Repetitive measurement

Background

The data capture can be manually controlled
(Single) or automatically updated (Repetitive).
In single measurement, the measurement is
activated by pressing the Trigger key.
In repetitive measurement, the measurement is
automatically done and the display is updated
according to the speed (timing) setting.

Panel operation

1. Press the Sing/Rep key repeatedly

until the “Repetitive Mode” message
appears on the display.

Sing/Rep

Repetitive Mode

2. The measurement update indicator (*) keeps

blinking and the measurement result is updated
on the display.

MEASUREMENT MODE

0.01234

0.2179

nS

D

*7

3. Press the Left/Right key repeatedly

to move the cursor to measurement
speed.

Speed Slow

4. Press the Up/Down key repeatedly

to select the time per update.
