BASIC MEASUREMENT
49
Delta mode (Pass/Fail test)
MEASUREMENT MODE
0.01234
0.2179
mF
D
*7
C L X B Z Y
Q D R G
Parallel
Hide Scale
Abs
Save Nom
LO
53.388mF
Hi
Lo 1.0000 mF
1.0000 mF
10mVac 1.5000kHz
Range
Speed Med
Auto Vm:549.8mV
Im:724.9pA
–
Norm
Value
Hi/Lo
Threshold Delta Mode
Abs %
For Pass/Fail test details, see page58.
Show circuit model or scale (pass/fail)
Background The center of the display can be filled with the
diagram of equivalent circuit model, or the
measurement scale with Pass/Fail test result. This
selects not only the diagram/scale but also
whether running the Pass/Fail test or just
measuring the value.
Panel operation Press F4 (Show/Hide scale) to view
the circuit model or scale.
Normal
MEASUREMENT MODE
0.01234
0.2179
mF
D
*7
C L X B Z Y
Q D R G
Parallel
Show Scale
50mVac 1.5000kHz
Range
Speed Med
Auto Vm:549.8mV
Im:724.9pA
–
Pass/Fail test
MEASUREMENT MODE
0.01234
0.2179
mF
D
*7
C L X B Z Y
Q D R G
Parallel
Hide Scale
Abs
Save Nom
HI
Hi Lo 20.0mF 0.00mF
50mVac 1.5000kHz
Range
Speed Med
Auto Vm:549.8mV
Im:724.9pA
–
%
Pass/Fail test For Pass/Fail test details, see page58.
