background image

PASS-FAIL

MODE

73

Configure the Average

Background

The Average function sets the number of samples
used, which are then averaged as the final output.
The number of samples varies from 1 to 256.

Panel operation

1. Press the Menu key, then F5

(System). The system configuration
appears.

Menu

F 5

Precision LCR Meter LCR-8101

5

:

Frequency

Software version 2.03 Oct 25 2008

RS-232

GPIB

Graph mode

Line frequency

Beep

GPIB address

:

:

OFF

50Hz

1MHz

Average

: 10

2. Press the Up/Down key and move

the cursor to Average.

Average

:

10

3. Use the numerical keys to enter the

number of samples to be averaged.
A maximum of 256 samples can be
selected for averaging.
