LCR-8000G Series User Manual
88
Item Selection
Enter graph mode
Panel operation 1. Press the Menu key. The main menu
appears.
Menu
MAIN MENU
AC MEAS
Rdc MEAS
MULTI STEP
GRAPH
SYSTEM
F 1
F 2
F 3
F 4
F 5
2. Press F4 (Graph). The Graph mode
display appears.
F 4
GRAPH MODE - Set
Manual Fit
Abs %
Start
Log(V) Lin(V)
View
Cs Ls Lp Q Cp D Z θ Rs Rp X G B Y
Sweep
Start
Stop
Freq
Speed
Step Size:
Cs Hi
Cs Lo
Nominal:
:
:
:
:
:
:
:
Drive level
50mV
1.00 V
10.000kHz
Fast
2 3 4 1
-99.500%
10.500%
100.00mF
F 1
F 2
F 3
F 4
F 5
F 6
