BASIC MEASUREMENT
47
Measurement Mode Overview
Enter measurement mode
Type AC C, L, X, B, Z, Y, Q, D, R, G, θ
DC Rdc
Panel operation 1. Press the Menu key. The main menu
appears.
Menu
MAIN MENU
AC MEAS
Rdc MEAS
MULTI STEP
GRAPH
SYSTEM
F 1
F 2
F 3
F 4
F 5
2. For Rdc measurement, press F2
(Rdc Meas).
For any other measurement, press
F1 (AC Meas). The measurement
mode display appears.
F 2
F 1
AC measurement
MEASUREMENT MODE
0.01234
0.2179
mF
D
*7
C L X B Z Y
Q D R G
Parallel
Hide Scale
Abs %
Save Nom
LO
53.388fF
Hi
Lo
+1.00%
–1.00%
50mVac 1.5000kHz
Range
Speed Med
Auto Vm:549.8mV
Im:724.9pA
–
DC measurement (Rdc)
MEASUREMENT MODE
156.35mΩ
*7
Hide Scale
Abs
Save Nom
HI
154.53mΩ
Hi
Lo
+1.00%
–1.00%
1.00Vdc
Range
Speed Med
Auto Vm:549.8mV
Im:724.9pA
%
