LCR-8000G Series User Manual

120

:graph:lo-lim

Set the minimum value for Y-axis in the graph
mode.
Parameter: real number up to 1^12 (1e+12)
Example: :graph:lo-lim -8.5e9
Note: The graph limits will only work whilst the
“autofit” function is set to “off”

:graph:lo-lim?

Returns minimum value for Y-axis of the graph
mode.

:graph:nom

Set the nominal value for the graph.
Parameter: 3, 1e-1, 100e1
Example: :graph:nom 1e-1
Note: Nominal can only be set if the graph limit is
set as a %(percentage)

:graph:nom?

Returns the current graph nominal.

:graph:logf

Selects the frequency scale type.
Parameter: on, off
Example: :(on) graph:logf on

:graph:logf?

Returns the current frequency scale type.
Returned parameter 1(on), 0(off).

:graph:limit

Selects absolute or relative plotting.
Parameter: perc( % relative), abs(absolute)
Example: :graph:limit abs

:graph:limit?

Returns the current graph plotting mode.
Returned parameter: 0(abs), 1(percentage)
