LCR-8000G Series User Manual

58

P

ASS-FAIL MODE

In the Pass/Fail test mode, measurement results are
compared with user-defined limits and the results
are displayed. Two types of tests are available: Single
and Multi-Step. The Single test shares the same
interface with the basic measurement, and tracks one
item. The Multi-Step test runs a program comprised
of multiple measurement items with different
parameters.

Single-step
configuration

Overview ...................................................................... 60

Configure beep setting ................................................ 61

Configure the Average ................................................. 62

Select test item and scale (Pass/Fail test) .................. 63

Set parameters ............................................................. 64

Single-step run

Run in Absolute mode ................................................. 66

Run in Percentage mode ............................................. 67

Run in Delta mode ...................................................... 68

Use display value as nominal ...................................... 69
