Multicast Outgoing Interface (OIF) list optimization
1
sm=1 ssm=0 hw=1 fast=1 slow=0 leaf=0 prun=0 tag=1 needRte=0 msdp_adv=1
AgeSltMsk=00000008, FID: 0x800e MVID: 1 , RegPkt 0, AvgRate 0 profile: none
2 (49.1.1.108, 229.0.0.1) in v49 (tag e4/9), Uptime 00:03:32 Rate 11257
Sparse Mode, RPT=0 SPT=1 Reg=0 L2Reg=1 RegSupp=0 RegProbe=0 LSrc=1 LRcv=1
Source is directly connected. RP 192.168.1.1
num_oifs = 1
immediate_oifs = 0, inherited_oifs = 1, blocked_oifs = 0
52,4/12(00:03:32/0) Flags:00000004
fast ports ethe 4/12
L3 (HW) 1: e4/12(VL52)
Flags (0x7046c8e1)
sm=1 ssm=0 hw=1 fast=1 slow=0 leaf=0 prun=0 tag=1 needRte=0 msdp_adv=1
AgeSltMsk=00000008, FID: 0x800e MVID: 1 , RegPkt 0, AvgRate 11257 profile: none
3 (49.1.1.108, 229.0.0.2) in v49 (tag e4/9), Uptime 00:03:32 Rate 11257
Sparse Mode, RPT=0 SPT=1 Reg=0 L2Reg=1 RegSupp=0 RegProbe=0 LSrc=1 LRcv=1
Source is directly connected. RP 192.168.1.1
num_oifs = 1
immediate_oifs = 0, inherited_oifs = 1, blocked_oifs = 0
52,4/12(00:03:32/0) Flags:00000004
fast ports ethe 4/12
L3 (HW) 1: e4/12(VL52)
Flags (0x7046c8e1)
sm=1 ssm=0 hw=1 fast=1 slow=0 leaf=0 prun=0 tag=1 needRte=0 msdp_adv=1
AgeSltMsk=00000008, FID: 0x800e MVID: 1 , RegPkt 0, AvgRate 11257 profile: none
Number of matching entries: 3
Syntax: show ip pim mcache fid fid-id
The fid-id variable allows you to display an entry that matches a specified fid.
Table 18 describes the output parameters of the show ip pim mcache fid 8 command.
TABLE 18 Output parameters of the show ip pim mcache fid 8 command
Field Description
Total entries in mcache Shows the total number of PIM mcache entries.
v Shows the interface name.
tag e Shows the VLAN tagged ethernet interface.
Uptime Shows the entry uptime.
Rate Shows the total packet count.
Sparse mode Shows that the PIM sparse mode is enabled.
RPT Sets the flag to 1, if the entry is on the RP tree, else sets the flag to 0.
SPT Sets the flag to 1, if the entry is on the source tree, or else sets the flag to 0.
Reg Sets the flag to 1, if the data registration is in progress, or else sets the flag to 0.
L2Reg Sets the flag to 1, if the source is directly connected to the router, or else sets the flag
to 0.
RegSupp Sets the flag to 1, if the register suppression timer is running, or else sets the flag to 0.
RegProbe Sets the flag to 1, if the mcache entry is entering the register probing period, or else
sets the flag to 0.
LSrc Sets the flag to 1, if the source is in a directly-connected interface, or else sets the flag
to 0.
LRcv Sets the flag to 1, if the receiver is directly connected to the router, or else sets the flag
to 0.
