Multi-Service IronWare Multicast Configuration Guide
57
53-1003032-02
Multicast Outgoing Interface (OIF) list optimization
1
describes the output from this command.
Displaying RP-to-group mappings
To display RP-to-group-mappings, enter the following command at any CLI level.
Brocade# show ip pim rp-map
Number of group-to-RP mappings: 6
Group address RP address
-------------------------------
1 239.255.163.1 99.99.99.5
2 239.255.163.2 99.99.99.5
3 239.255.163.3 99.99.99.5
4 239.255.162.1 99.99.99.5
5 239.255.162.2 43.43.43.1
6 239.255.162.3 99.99.99.5
Syntax: show ip pim [vrf vrf-name] rp-map
The vrf option allows you to display candidate RP-to-group mappings for the VRF instance identified
by the vrf-name variable.
This display shows the following information.
Displaying RP Information for a PIM Sparse group
To display RP information for a PIM Sparse group, enter the following command at any CLI level.
Syntax: show ip pim [vrf vrf-name] rp-hash group-addr
TABLE 11
Output from the show ip pim rp-candidate command
This field...
Displays...
Candidate-RP-advertisement in
Indicates how many seconds will pass before the BSR sends the next RP
message.
NOTE: This field appears only if this device is a candidate RP.
RP
Indicates the IP address of the Rendezvous Point (RP).
NOTE: This field appears only if this device is a candidate RP.
group prefixes
Indicates the multicast groups for which the RP listed by the previous field is a
candidate RP.
NOTE: This field appears only if this device is a candidate RP.
Candidate-RP-advertisement
period
Indicates how frequently the BSR sends candidate RP advertisement
messages.
NOTE: This field appears only if this device is a candidate RP.
TABLE 12
Output of the show ip pim rp-map command
This field...
Displays...
Group address
Indicates the PIM Sparse multicast group address using the listed RP.
RP address
Indicates the IP address of the Rendezvous Point (RP) for the listed PIM Sparse group.
Brocade# show ip pim rp-hash 239.255.162.1
RP: 207.95.7.1, v2
Info source: 207.95.7.1, via bootstrap
